Solid Wall Pipes

KAI Pressure Pipes are produced with pressure ratings ranging from PN4 to PN25. KAI Pressure Pipes PN4 can be used for drainage while the higher pressure classes are used for pressurized fluid systems.

Download

E - Catalogue

Applications

  • ♦Potable Water
  • ♦Brackish Water
  • ♦Treated Water
  • ♦Domestic and Industrial Gas Pipes
  • ♦Irrigation Systems
  • ♦Industrial Process Lines
  • ♦PE Lining Applications (More to Come)

Advantages

  • ♦Non-Corrosive
  • ♦Energy Saving Via Decreased Pressure Loss
  • ♦Resistant to Aging
  • ♦Resistant to Radiation
  • ♦Resistant to Chemicals, Untreated Industrial Waste Water and Other Corrosive Materials
  • ♦Resistant to Ultra-Violet Rays
  • ♦Perfectly Weldable
  • ♦Freeze Resistant
  • ♦Hygienic and Non-Toxic
  • ♦Easy Installation

Dimensions

KAI Pressure Pipes are available in sizes ranging from 16mm to 800mm. Straight pipes are available in unit lengths of 12m or more. Coil pipes are available in rolls of 50m or 100m and up to 300m, depending on sizes. Available ranges are 16mm to 110mm.

Solid Wall Chart

SDR

Nominal Diameter

17

Mean ID
mmThickness
mm

11

Mean ID
mmThickness
mm
32     25.73.0
40     32.2 3.7
50     40.4 4.6
63     50.8 5.8
75 65.7 4.5 60.7 6.8
90 78.8 5.4 72.8 8.2
110 96.3 6.6 89.0 10.0
125 109.6 7.4 101.0 11.4
140 122.8 8.3 113.3 12.7
160 140.3 9.5 129.4 14.6
180 157.8 10.7 144.9 16.4
200 175.3 11.9 160.9 18.2
225 197.2 13.4 181.1 20.5
250 219.3 14.8 201.3 22.7
280 244.8 16.6 225.5 25.4
315 275.4 18.7 253.6 28.6
355 310.2 21.1 285.8 32.2
400 349.7 23.7 322.0 36.3
450 393.4 26.7 362.2 40.9
500 437.0 29.7 402.5 45.4
560 489.6 33.2 450.9 50.8
630 550.7 37.4 507.1 57.2
710 620.6 42.1
800 699.4 47.4
